| Producent |
GIGABYTE |
| Wyposażenie dodatkowe |
Norton® Internet Security (OEM version), LAN bandwidth management software |
| Maksymalna wielkość pamięci |
192 GB |
| Chipset płyty głównej |
AMD B650 |
| Wymiary [S x W] (mm) |
305 x 224 |
| Opakowanie |
BOX |
| Gniazdo procesora |
Socket AM5 |
| Standard pamięci |
DDR5-4400, DDR5-4800, DDR5-5200, DDR5-5600 (OC), DDR5-6000 (OC), DDR5-6200 (OC), DDR5-6400 (OC), DDR5-6600 (OC), DDR5-6800 (OC), DDR5-7000 (OC), DDR5-7200 (OC), DDR5-7600 (OC), DDR5-7800 (OC), DDR5-8000 (OC) |
| Format płyty |
ATX |
| Wbudowana karta graficzna |
Brak lub AMD Radeon™ Graphics (zależy od procesora) |
| Obsługiwane typy procesorów |
AMD Ryzen™ |
| Uwagi do procesora |
Support for: AMD Ryzen™ 7000/ Ryzen™ 8000 Series Processors |
| BIOS |
256 Mbit flash, AMI UEFI BIOS PnP 1.0a DMI 2.7 WfM 2.0 SM BIOS 2.7 ACPI 5.0 |
| Tryb pracy pamięci RAM |
Dual Channel |
| Gniazda karty graficznej |
HDMI, DisplayPort |
| Uwagi do karty graficznej |
1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz, Support for HDMI 2.1 version and HDCP 2.3, Support native HDMI 2.1 TMDS compatible ports, 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz, Support for DisplayPort 1.4 version and HDR, Graphics specifications may vary depending on CPU support |
| Zintegrowana karta dźwiękowa |
Realtek® 8-Channel High Definition Audio CODEC |
| Gniazda karty dźwiękowej |
Wewnętrzne gniazdo audio przedniego panelu, 3x Audio Jack |
| Złącza PCI Express x16 |
3 |
| Uwagi do złącz PCI |
1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:, - AMD Ryzen™ 7000 Series Processors support PCIe 4.0 x16 mode, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode, The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only , one graphics card is to be installed, be sure to install it in the PCIEX16, Chipset:, - 2 x PCI Express x16 slots, supporting PCIe 3.0 and running at x1 , (PCIEX1_1/2) |
| Port Bluetooth |
Bluetooth V5.3 |
| Port równoległy (LPT) |
Brak |
| Inne porty i gniazda |
CPU fan header, CPU fan/water cooling pump header, 2x system fan headers, System fan/water cooling pump header, 2x Addressable LED strip headers, 2x RGB (RGBW) LED strip headers, CPU cooler LED strip/RGB LED strip extension cable header, Front panel header, Gniazdo modułu TPM, Reset button, Reset jumper, Clear CMOS jumper, 2x SMA antenna connectors (2T2R), Q-Flash Plus button |
| Gniazdo zasilania |
ATX (24-pin) + ATX12V (8-pin) + ATX12V (4-pin) |
| Uwagi do pamięci RAM |
Support up to 192 GB (48 GB single DIMM capacity) of system memory, Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules, Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme, Memory Profile (XMP) memory modules |
| Okres rękojmi w miesiącach |
36 |
| Zintegrowany kontroler SATA |
Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,10 + 3x M.2 - RAID 0, 1, 10 |
| Uwagi do kontrolera SATA |
M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key,, type 25110/2580 SSDs:, - AMD Ryzen™ 7000 Series Processors support PCIe 5.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 1/Phoenix 2 Processors support PCIe 4.0 , x4/x2 SSDs, 1 x M.2 connector (M2B_CPU), integrated in the CPU, supporting Socket 3, , M key, type 25110/2580 SSDs:, - AMD Ryzen™ 7000 Series Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x2 SSDs, 1 x M.2 connector (M2C_SB), integrated in the Chipset, supporting Socket 3,, M key, type 25110/2580 PCIe 4.0 x4/x2 SSDs, 4 x SATA 6Gb/s connectors, RAID 0, RAID 1, and RAID 10 support for SATA storage devices, RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices |
| Port Wi-Fi |
IEEE 802.11a/b/g/n/ac/ax |
| Port LAN |
1x 2,5 Gigabit LAN 100/1000/2500 Mb/s (Realtek®) |
| Port PS/2 |
Brak |
| Port szeregowy (COM) |
1x wewnętrzne gniazdo portu COM |
| Maksymalna ilość portów USB 2.0 |
7 |
| Maksymalna ilość portów USB 3.x |
10 |
| Porty USB na panelu tylnym |
3x USB 2.0 + 3x USB 3.0 + 1x USB 3.1 + 1x USB 3.1 Type-C |
| Gniazda USB na płycie głównej |
2x USB 2.0 (4 porty) + 2x USB 3.0 (4 porty) + 1x USB 3.2 Type-C (1 port) |
| Cechy |
B650 GAMING X AX V2;ATX |
| Baza SCIP |
Nie |
| Ilość złącz pamięci DDR5 |
4 |
| Uwagi do WiFi / BT |
Realtek® Wi-Fi 6E RTL8852CE (PCB rev. 1.0), WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands, Support for 11ax 160MHz wireless standard |
