Płyta Gigabyte B840M DS3H /AMD B840/DDR5/SATA3/M.2/USB3.0/PCIe4.0/AM5/M-ATX

INDEKS 4719331868437

KOD ID PGGBA5M52000

CENA:
597.99 zł brutto

Dostępnych w magazynie: 8
Dostawa do sklepu stacjonarnego trwa 1-2 dni robocze.




Udostępnij

Szczegóły

Producent GIGABYTE
Maksymalna wielkość pamięci 256 GB
Chipset płyty głównej AMD B840
Wymiary [S x W] (mm) 244 x 244
Opakowanie BOX
Gniazdo procesora Socket AM5
Standard pamięci DDR5-8200 (OC), DDR5-8000 (OC), DDR5-7800 (OC), DDR5-7600 (OC), DDR5-7200 (OC), DDR5-7000 (OC), DDR5-6800 (OC), DDR5-6666 (OC), DDR5-6600 (OC), DDR5-6400 (OC), DDR5-6200 (OC), DDR5-6000 (OC), DDR5-5600 (OC), DDR5-5200, DDR5-4800, DDR5-4400
Format płyty Micro-ATX
Wbudowana karta graficzna Brak lub AMD Radeon™ Graphics (zależy od procesora)
Obsługiwane typy procesorów AMD Ryzen™
Uwagi do procesora AMD Ryzen™ 9000 Series Processors, AMD Ryzen™ 8000 Series Processors, AMD Ryzen™ 7000 Series Processors
BIOS 256 Mbit flash AMI UEFI; PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Tryb pracy pamięci RAM Dual Channel
Gniazda karty graficznej HDMI, 2x DisplayPort
Uwagi do karty graficznej Integrated Graphics Processor with AMD Radeon™ Graphics support:, - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz, Support for HDMI 2.1 version, HDCP 2.3, and HDR, Support for native HDMI 2.1 TMDS compatible ports, - 2 x DisplayPorts, supporting a maximum resolution of 3840x2160@144 Hz, Support for DisplayPort 1.4 version, Graphics specifications may vary depending on CPU support, Support for up to quad-display at the same time
Zintegrowana karta dźwiękowa Realtek ® 7.1 Surround Sound High Definition Audio CODEC
Gniazda karty dźwiękowej 3x Audio Jack, Wewnętrzne gniazdo audio przedniego panelu
Złącza PCI Express x16 2
Uwagi do złącz PCI 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:, - AMD Ryzen™ 9000/7000 Series Processors support PCIe 4.0 x16 mode, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode, The PCIEX16 slot can only support a graphics card or an NVMe SSD, If only one graphics card is to be installed, be sure to install it in , the PCIEX16 slot, Chipset:, - 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x4 (PCIEX4)
Port Bluetooth Nie
Port równoległy (LPT) Brak
Inne porty i gniazda CPU fan header, CPU fan/water cooling pump header, System fan header, System fan/water cooling pump header, 2x Addressable RGB Gen2 LED strip header, RGB LED Header, Gniazdo modułu TPM, Reset jumper, Clear CMOS jumper, Q-Flash Plus button
Gniazdo zasilania ATX (24-pin) + ATX12V (8-pin)
Uwagi do pamięci RAM Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules, Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and , Extreme Memory Profile (XMP) memory modules
Uwagi do karty dźwiękowej You can change the functionality of an audio jack using the audio software, To configure 7.1-channel audio, access the audio software for audio setting
Okres rękojmi w miesiącach 36
Zintegrowany kontroler SATA Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,10 + 2x M.2 - RAID 0,1,5,10
Uwagi do kontrolera SATA 1x M.2 connector (M2A_CPU), , integrated in the CPU, supporting Socket 3, , M key, type 2580/2280 SSDs:, - AMD Ryzen™ 9000/7000 Series Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs, - 1 x M.2 connector (M2B_CPU), integrated in the CPU, supporting Socket 3, , M key, type, type 25110/22110/2580/2280 SSDs:, - AMD Ryzen™ 9000/7000 Series Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x2 SSDs, 4 x SATA 6Gb/s connectors:, RAID 5 is only available on AMD Ryzen™ 9000 Series Processors.
Port Wi-Fi Nie
Port LAN 1x 2,5 Gigabit LAN 100/1000/2500 Mb/s (Realtek®)
Port PS/2 Port combo klawiatury/myszy PS/2
Port szeregowy (COM) 1x wewnętrzne gniazdo portu COM
Maksymalna ilość portów USB 2.0 8
Maksymalna ilość portów USB 3.x 7
Porty USB na panelu tylnym 4x USB 2.0 + 2x USB 3.0 + 1x USB 3.0 Type C
Gniazda USB na płycie głównej 2x USB 2.0 (4 porty) + 1x USB 3.0 (2 porty) + 1x USB 3.0 Type-C (1 port)
Cechy B840M DS3H
Baza SCIP Nie
Ilość złącz pamięci DDR5 4
